![CDATA[Technical specifications: Type of input: supply, mains voltage Terminal marking: L, N Input voltage range: 100Vac 240Vac Max. input current: 40mA (@120Vac), 20mA (@240Vac) Mains frequency: 50Hz / 60Hz Power consumption: max. 5.3W Switch-on start-up time: 250ms Type of output: DALI bus supply Terminal marking: DA+, DA? Output voltage range: 12Vdc 20.5Vdc guaranteed DALI output current: 180mA maximum DALI output current: 250mA no-load proof: Yes short-circuit proof: Yes impulse voltage category: II pollution degree: 2 rated insulation voltage: 250V insulation output (DA+,DA-) / supply (L,N): reinforced insulation insulation test voltage: 3000Vac transport and storage temperature: -20 to +75 degrees Celsius operating temperature: -10 to +55 degrees Celsius relative humidity, non-condensing: 15% 90%]]>
